Axin2-d2EGFP
(Plasmid #21276)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 21276 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    d2EGFP-1
  • Backbone manufacturer
    Clontech (discontinued)
  • Backbone size w/o insert (bp) 4300
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Axin2 promoter
  • Alt name
    Axin2
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    5600
  • Entrez Gene
    Axin2 (a.k.a. A, Axi1, Axil, Condu, Conductin)
  • Tag / Fusion Protein
    • d2EGFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (not destroyed)
  • 3′ cloning site HindIII / SmaI (destroyed during cloning)
  • 5′ sequencing primer EGFP-N
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The 5.6-kb DNA fragment was excised from Axin2-Luciferase using KpnI and HindIII (the HindIII site was filled in with Klenow DNA polymerase) and cloned into the KpnI- and SmaI-digested pd2EGFP-1 vector.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Axin2-d2EGFP was a gift from Frank Costantini (Addgene plasmid # 21276 ; http://n2t.net/addgene:21276 ; RRID:Addgene_21276)
  • For your References section:

    Wnt/beta-catenin/Tcf signaling induces the transcription of Axin2, a negative regulator of the signaling pathway. Jho EH, Zhang T, Domon C, Joo CK, Freund JN, Costantini F. Mol Cell Biol. 2002 Feb . 22(4):1172-83. 10.1128/MCB.22.4.1172-1183.2002 PubMed 11809808
