CUP1-∆ssCPY*-mGFP
(Plasmid #212197)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 212197 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pRS316
  • Backbone size w/o insert (bp) 4887
  • Total vector size (bp) 7776
  • Modifications to backbone
    pCUP1-∆ssCPY*-mGFP
  • Vector type
    Yeast Expression
  • Selectable markers
    URA3

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Carboxypeptidase Y variant
  • Alt name
    ∆ssCPY*
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    1536
  • Mutation
    Deletion signal peptide, G255A mutation
  • Entrez Gene
    PRC1 (a.k.a. YMR297W, CPY1, LBC1)
  • Promoter CUP1
  • Tag / Fusion Protein
    • mEGFP (monomeric version EGFP, A206K mutation)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer tgtatcaattgcattataatatcttcttgt
  • 3′ sequencing primer aactaattacatgatatcgacaaaggaaaa
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CUP1-∆ssCPY*-mGFP was a gift from Mark Leake & Chris MacDonald (Addgene plasmid # 212197 ; http://n2t.net/addgene:212197 ; RRID:Addgene_212197)
