LD-RA
(Plasmid #209863)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 209863 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    mEmerald-C1
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ddRFP A
  • Species
    Synthetic
  • Promoter CMV
  • Tag / Fusion Protein
    • Hairpin domain of GPAT4 MNFQYISLRLTVLWGLGVLIRYCFLLPLRIALAFTGISLLVVGTTVVGYLPNGRFKEF (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

mEmerald was replaced with ddRFP A

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    LD-RA was a gift from Sarah Cohen (Addgene plasmid # 209863 ; http://n2t.net/addgene:209863 ; RRID:Addgene_209863)

  • For your References section:

    Contact-FP: A Dimerization-Dependent Fluorescent Protein Toolkit for Visualizing Membrane Contact Site Dynamics. Miner GE, Smith SY, Showalter WK, So CM, Ragusa JV, Powers AE, Zanellati MC, Hsu CH, Marchan MF, Cohen S. Contact (Thousand Oaks). 2024 Feb 4;7:25152564241228911. doi: 10.1177/25152564241228911. eCollection 2024 Jan-Dec. 10.1177/25152564241228911 PubMed 38327561
