Stx5L-mCherry
(Plasmid #209844)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 209844 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pmCherry-N1
  • Backbone manufacturer
    Clontech
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    STX5
  • Alt name
    Syntaxin 5
  • Species
    H. sapiens (human)
  • Mutation
    Wildtype Stx5 (with 55M)
  • GenBank ID
    NM_003164.5
  • Entrez Gene
    STX5 (a.k.a. CDG2AA, SED5, STX5A)
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer pEGFP-cmv
  • 3′ sequencing primer mCherry_N1
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Stx5L-mCherry was a gift from Geert van den Bogaart (Addgene plasmid # 209844 ; http://n2t.net/addgene:209844 ; RRID:Addgene_209844)

  • For your References section:

    Congenital disorder of glycosylation caused by starting site-specific variant in syntaxin-5. Linders PTA, Gerretsen ECF, Ashikov A, Vals MA, de Boer R, Revelo NH, Arts R, Baerenfaenger M, Zijlstra F, Huijben K, Raymond K, Muru K, Fjodorova O, Pajusalu S, Ounap K, Ter Beest M, Lefeber D, van den Bogaart G. Nat Commun. 2021 Oct 28;12(1):6227. doi: 10.1038/s41467-021-26534-y. 10.1038/s41467-021-26534-y PubMed 34711829
