pBJ077_zACNE20_E1b_2xLyn_mCherry
(Plasmid #209281)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 209281 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    zACNE20_E1b
  • Backbone size w/o insert (bp) 7671
  • Total vector size (bp) 8511
  • Vector type
    Zebrafish Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mCherry2
  • Species
    Synthetic
  • Insert Size (bp)
    840
  • Promoter zACNE20_E1b

Cloning Information

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBJ077_zACNE20_E1b_2xLyn_mCherry was a gift from Adam Cohen (Addgene plasmid # 209281 ; http://n2t.net/addgene:209281 ; RRID:Addgene_209281)

  • For your References section:

    A bioelectrical phase transition patterns the first vertebrate heartbeats. Jia BZ, Qi Y, Wong-Campos JD, Megason SG, Cohen AE. Nature. 2023 Oct;622(7981):149-155. doi: 10.1038/s41586-023-06561-z. Epub 2023 Sep 27. 10.1038/s41586-023-06561-z PubMed 37758945
