pDisplay-GRAB_r5-HTmut
(Plasmid #208714)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 208714 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDisplay
  • Backbone manufacturer
    pDisplay
  • Backbone size w/o insert (bp) 6550
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Red fluorescent 5-HT sensor GRAB_r5-HTmut
  • Species
    H. sapiens (human), M. musculus (mouse)
  • Insert Size (bp)
    1992
  • Promoter CMV

Cloning Information

  • Cloning method Gibson Cloning

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDisplay-GRAB_r5-HTmut was a gift from Yulong Li (Addgene plasmid # 208714 ; http://n2t.net/addgene:208714 ; RRID:Addgene_208714)

  • For your References section:

    Dual-color GRAB sensors for monitoring spatiotemporal serotonin release in vivo. Deng F, Wan J, Li G, Dong H, Xia X, Wang Y, Li X, Zhuang C, Zheng Y, Liu L, Yan Y, Feng J, Zhao Y, Xie H, Li Y. bioRxiv 2023.05.27.542566 10.1101/2023.05.27.542566
