pcDNA3.1-CRISPR-Puro
(Plasmid
#208646)
-
Purpose(Empty Backbone) pcDNA3.1 based empty vector for transient transfection of sgRNA-cas9. U6 promoter ~ puro Res cloned from lentiCRISPRv2 (Addgene#52961), lenti virus sequences not included.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 208646 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3.1 (-)
-
Backbone manufacturerThermo Fisher (Invitrogen)
-
Vector typeMammalian Expression, CRISPR
- Promoter CMV and U6 in tandem
-
Selectable markersNeomycin (select with G418), Puromycin
-
Tags
/ Fusion Proteins
- Flag (C terminal on insert)
- p2A (C terminal on insert)
- Puromycin resistant gene (C terminal on insert)
- Clawed frog nucleoplasmin NLS (C terminal on insert)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Growth instructionsWe use stbl3
-
Copy numberHigh Copy
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byThe U6p-BsmBIflanking-Cas9-NLS-p2A-PuroRes cassette was cloned from lentiCRISPRv2 (Addgene#52961), lenti virus related sequences was not included.
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Lenti virus related sequences was not included, for use at Biosafety Level 1. Clone sgRNA as discribed in the document of lentiCRISPRv2 with BsmBI. Note that CMV enhancer-promoter in pcDNA3.1 is not removed, thus the sgRNA would be promoted by tandem CMV-U6 promoter.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA3.1-CRISPR-Puro was a gift from Quanfu Ma (Addgene plasmid # 208646 ; http://n2t.net/addgene:208646 ; RRID:Addgene_208646)
