pcDNA3.1-CRISPR-Puro
(Plasmid #208646)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 208646 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA3.1 (-)
  • Backbone manufacturer
    Thermo Fisher (Invitrogen)
  • Vector type
    Mammalian Expression, CRISPR
  • Promoter CMV and U6 in tandem
  • Selectable markers
    Neomycin (select with G418), Puromycin
  • Tags / Fusion Proteins
    • Flag (C terminal on insert)
    • p2A (C terminal on insert)
    • Puromycin resistant gene (C terminal on insert)
    • Clawed frog nucleoplasmin NLS (C terminal on insert)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Growth instructions
    We use stbl3
  • Copy number
    High Copy

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    The U6p-BsmBIflanking-Cas9-NLS-p2A-PuroRes cassette was cloned from lentiCRISPRv2 (Addgene#52961), lenti virus related sequences was not included.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Lenti virus related sequences was not included, for use at Biosafety Level 1. Clone sgRNA as discribed in the document of lentiCRISPRv2 with BsmBI. Note that CMV enhancer-promoter in pcDNA3.1 is not removed, thus the sgRNA would be promoted by tandem CMV-U6 promoter.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1-CRISPR-Puro was a gift from Quanfu Ma (Addgene plasmid # 208646 ; http://n2t.net/addgene:208646 ; RRID:Addgene_208646)
