pCX:B3-α4ΔICD
(Plasmid
#208513)
-
PurposeddGFP-B3-inserted Pcdhα4 lacking an intracellular domain (ICD)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 208513 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepCX
- Backbone size w/o insert (bp) 4778
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namePcdha4
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)2967
-
Entrez GenePcdha4 (a.k.a. Cnr1, Crnr1)
- Promoter Chicken β-actin
-
Tag
/ Fusion Protein
- HA tag (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site EcoRI (not destroyed)
- 3′ cloning site BglII (not destroyed)
- 5′ sequencing primer CTTCTGGCGTGTGACCGG
- 3′ sequencing primer CCATATGTCCTTCCGAGTG (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCX:B3-α4ΔICD was a gift from Takeharu Nagai (Addgene plasmid # 208513 ; http://n2t.net/addgene:208513 ; RRID:Addgene_208513) -
For your References section:
Visualization of trans-interactions of a protocadherin-alpha between processes originating from single neurons. Kanadome T, Hoshino N, Nagai T, Yagi T, Matsuda T. iScience. 2023 Jul 17;26(7):107238. doi: 10.1016/j.isci.2023.107238. eCollection 2023 Jul 21. 10.1016/j.isci.2023.107238 PubMed 37534169
