Addgene

GW1-rogRFP2
(Plasmid #207876)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 207876 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    GW1
  • Backbone size w/o insert (bp) 5274
  • Total vector size (bp) 6660
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    rogRFP2
  • Alt name
    roGFP2-mApple
  • Species
    Synthetic
  • Insert Size (bp)
    1385
  • Promoter CMV

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CTGAATCGGAGTGAGTGC
  • 3′ sequencing primer CAAATGTGGTATGGCTGATT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GW1-rogRFP2 was a gift from Mathew Tantama (Addgene plasmid # 207876 ; http://n2t.net/addgene:207876 ; RRID:Addgene_207876)

  • For your References section:

    Neuron Activity Dependent Redox Compartmentation Revealed with a Second Generation Red-Shifted Ratiometric Sensor. Radhakrishnan S, Norley J, Wendt S, LeRoy N, Hall H, Norcross S, Doan S, Snaider J, MacVicar BA, Weake VM, Huang L, Tantama M. ACS Chem Neurosci. 2020 Sep 2;11(17):2666-2678. doi: 10.1021/acschemneuro.0c00342. Epub 2020 Aug 21. 10.1021/acschemneuro.0c00342 PubMed 32786310
