pgk-ATG-frt
(Plasmid #20734)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 20734 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBluescriptII KS
  • Backbone size w/o insert (bp) 2970
  • Vector type
    Mouse Targeting

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pgk-ATG-frt-SAdpA-tetO
  • Insert Size (bp)
    1902

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer T3
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pgk-ATG-frt was a gift from Rudolf Jaenisch (Addgene plasmid # 20734 ; http://n2t.net/addgene:20734 ; RRID:Addgene_20734)

  • For your References section:

    Efficient method to generate single-copy transgenic mice by site-specific integration in embryonic stem cells. Beard C, Hochedlinger K, Plath K, Wutz A, Jaenisch R. Genesis. 2006 Jan . 44(1):23-8. 10.1002/gene.20180 PubMed 16400644
