This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 20730 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepBluescriptII SK
- Backbone size w/o insert (bp) 2970
-
Vector typeMouse Targeting
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameCol1A-frt-hygro-pA
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)10324
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site XhoI (not destroyed)
- 3′ cloning site SpeI (not destroyed)
- 5′ sequencing primer T7
- 3′ sequencing primer T3 (Common Sequencing Primers)
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
There are a few mismatches between the author's sequence and Addgene's sequence. The discrepancies are in the targeting arms and will not affect function.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
Col1a-frt-hygro-pA was a gift from Rudolf Jaenisch (Addgene plasmid # 20730 ; http://n2t.net/addgene:20730 ; RRID:Addgene_20730) -
For your References section:
Efficient method to generate single-copy transgenic mice by site-specific integration in embryonic stem cells. Beard C, Hochedlinger K, Plath K, Wutz A, Jaenisch R. Genesis. 2006 Jan . 44(1):23-8. 10.1002/gene.20180 PubMed 16400644
