pGL4.23-5xE-box
(Plasmid #206841)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 206841 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pGL4.23[luc2/minP]
  • Backbone manufacturer
    Promega
  • Backbone size w/o insert (bp) 4283
  • Total vector size (bp) 4595
  • Vector type
    Luciferase

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    5x E-box ((GCCACGTGCA)
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    312

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    AZENTA Life Sciences, GENEWIZ Germany.

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pGL4.23-5xE-box was a gift from Tassula Proikas-Cezanne (Addgene plasmid # 206841 ; http://n2t.net/addgene:206841 ; RRID:Addgene_206841)

  • For your References section:

    The ABL-MYC axis controls WIPI1-enhanced autophagy in lifespan extension. Sporbeck K, Haas ML, Pastor-Maldonado CJ, Schussele DS, Hunter C, Takacs Z, Diogo de Oliveira AL, Franz-Wachtel M, Charsou C, Pfisterer SG, Gubas A, Haller PK, Knorr RL, Kaulich M, Macek B, Eskelinen EL, Simonsen A, Proikas-Cezanne T. Commun Biol. 2023 Aug 24;6(1):872. doi: 10.1038/s42003-023-05236-9. 10.1038/s42003-023-05236-9 PubMed 37620393
