mc2 neo EF1a
(Plasmid
#206220)
-
Purpose(Empty Backbone) For expressing cloned exons as circular RNA. Alternatively, for expressing cDNA (if the EcoRI-XhoI restriction fragment is also removed).
-
Depositing Labs
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 206220 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3.1(+) CircRNA Mini Vector
-
Backbone manufacturerAddgene ID 60648
-
Vector typeMammalian Expression, Synthetic Biology
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameNone
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
ZKSCAN1 intron 1 (partial) & ZKSCAN1 intron 3 (partial) separated by a pair of BsmBI restriction sites. 5' Cloning Site: EcoRI (not destroyed), 3' Cloning Site: XhoI (not destroyed). The mc2 and pF mc2 series of plasmids were designed and created by Dr Brett Stringer in the laboratory of Prof Simon Conn. They are based on the original circRNA mini vector design of Liang & Wilusz, 2014. The pair of BsmBI restriction sites is the cloning site for DNA specifying the RNA sequence to be circularised. For cloning cDNA, the 5' restriction site should be either NheI, BmtI, AflII, HindIII, Acc65I, KpnI, Eco53kI, SacI, BamHI, SpeI, BstXI or EcoRI and the 3' restriction site should be either XhoI, PspXI, XbaI, EcoO109I, PspOMI or ApaI. The CMV enhancer/promoter of Addgene plasmid ID 60648 also was replaced with the EF1a promoter from Addgene plasmid ID 98290. Please visit https://doi.org/10.1101/2023.11.21.568171 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
mc2 neo EF1a was a gift from Simon Conn & Brett Stringer (Addgene plasmid # 206220 ; http://n2t.net/addgene:206220 ; RRID:Addgene_206220) -
For your References section:
Versatile toolkit for highly-efficient and scarless overexpression of circular RNAs. Stringer BW, Gabryelska M, Marri S, Clark L, Lin H, Gantley L, Liu R, Wilusz JE, Conn VM, Conn SJ. bioRxiv. 2023 Nov 22:2023.11.21.568171. doi: 10.1101/2023.11.21.568171. Preprint. 10.1101/2023.11.21.568171 PubMed 38045421
