pAAV-Tnnt2-GFP-LA
(Plasmid #206198)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 206198 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    addgene#165036
  • Backbone manufacturer
    Yuxuan Guo
  • Backbone size w/o insert (bp) 4256
  • Total vector size (bp) 6965
  • Vector type
    AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Lmna
  • Alt name
    lamin A/C
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2709
  • Entrez Gene
    LMNA (a.k.a. CDCD1, CDDC, CMD1A, CMT2B1, EMD2, FPL, FPLD, FPLD2, HGPS, IDC, LDP1, LFP, LGMD1B, LMN1, LMNC, LMNL1, MADA, PRO1)
  • Promoter Tnnt2
  • Tag / Fusion Protein
    • GFP (N terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer GATCACATGGTCCTGCTGG
  • 3′ sequencing primer AAGATCGGATCCTCAGGCG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-Tnnt2-GFP-LA was a gift from Yuxuan Guo (Addgene plasmid # 206198 ; http://n2t.net/addgene:206198 ; RRID:Addgene_206198)

  • For your References section:

    Non-cell-Autonomous Cardiomyocyte Regulation Complicates Gene Supplementation Therapy for Lmna-Associated Cardiac Defects in Mice. Sun Y, Guo C, Chen Z, Lin J, Yang L, Zhang Y, Wu C, Zhao D, Jardin B, Pu WT, Zhao M, Dong E, Hu X, Zhang S, Guo Y. J Am Coll Cardiol Basic Trans Science. null2024, 0 (0). 10.1016/j.jacbts.2024.06.004
