Bn R52A, R54A pMT2
(Plasmid #206087)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 206087 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMT2
  • Backbone manufacturer
    Genetics Institute Inc
  • Backbone size w/o insert (bp) 5163
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    cacna1b
  • Alt name
    Cav2.2 alpha1B
  • Species
    O. cuniculus (rabbit)
  • Mutation
    R52A, R54A
  • Entrez Gene
    CACNA1B
  • Promoter Ad MLP/TPL/SV40

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer AGCTTGAGGTGTGGCAGGCTT
  • 3′ sequencing primer GGTCGAACCATGATGGCAGC
    • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Yasuo Mori

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

5' end of Cav2.2 DNA is very GC rich

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Bn R52A, R54A pMT2 was a gift from Annette Dolphin (Addgene plasmid # 206087 ; http://n2t.net/addgene:206087 ; RRID:Addgene_206087)

  • For your References section:

    N terminus is key to the dominant negative suppression of Ca(V)2 calcium channels: implications for episodic ataxia type 2. Page KM, Heblich F, Margas W, Pratt WS, Nieto-Rostro M, Chaggar K, Sandhu K, Davies A, Dolphin AC. J Biol Chem. 2010 Jan 8;285(2):835-44. doi: 10.1074/jbc.M109.065045. Epub 2009 Nov 10. 10.1074/jbc.M109.065045 PubMed 19903821
