pPV-EF1α-mRxxFP1(DMDex55_10)-iP-A
(Plasmid
#204622)
-
PurposeSingle-strand annealing (SSA) vector for monitoring crRNA(DMDex55)'s activity. DMD intron 55 region (downstream of exon 55). Puromycin selectable.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 204622 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepPV
- Backbone size w/o insert (bp) 6200
-
Vector typeMammalian Expression
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemRFP1
-
SpeciesSynthetic
-
Insert Size (bp)2100
- Promoter EF1a
Cloning Information
- Cloning method Ligation Independent Cloning
- 5′ sequencing primer GGGTCTCTGTCGAGCccaactatacataacaaaactccataatag
- 3′ sequencing primer AGGTCTCACGGTAGCgcaacaactcaccccattgttgg (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pPV-EF1α-mRxxFP1(DMDex55_10)-iP-A was a gift from Akitsu Hotta (Addgene plasmid # 204622 ; http://n2t.net/addgene:204622 ; RRID:Addgene_204622) -
For your References section:
Dual CRISPR-Cas3 system for inducing multi-exon skipping in DMD patient-derived iPSCs. Kita Y, Okuzaki Y, Naoe Y, Lee J, Bang U, Okawa N, Ichiki A, Jonouchi T, Sakurai H, Kojima Y, Hotta A. Stem Cell Reports. 2023 Sep 12;18(9):1753-1765. doi: 10.1016/j.stemcr.2023.07.007. Epub 2023 Aug 24. 10.1016/j.stemcr.2023.07.007 PubMed 37625413
