pHIT342
(Plasmid
#204514)
-
PurposeBacterial expression of SYP-1 N-terminal fragment with 6xHis and maltose binding protein tags for use as an antigen
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 204514 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepHIT198 (derived from pET-28a)
- Backbone size w/o insert (bp) 6442
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameN-terminal fragment of syp-1 (C. elegans)
-
SpeciesC. elegans (nematode)
- Promoter T7lac
-
Tag
/ Fusion Protein
- 6xHis, MBP (N terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NotI (unknown if destroyed)
- 3′ cloning site XhoI (unknown if destroyed)
- 5′ sequencing primer MBP_sense
- 3′ sequencing primer T7 terminator, reverse primer (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pHIT342 was a gift from Yuji Kohara (Addgene plasmid # 204514 ; http://n2t.net/addgene:204514 ; RRID:Addgene_204514) -
For your References section:
A small RNA system ensures accurate homologous pairing and unpaired silencing of meiotic chromosomes. Tabara H, Mitani S, Mochizuki M, Kohara Y, Nagata K. EMBO J. 2023 Jun 1;42(11):e105002. doi: 10.15252/embj.2020105002. Epub 2023 Apr 20. 10.15252/embj.2020105002 PubMed 37078421
