pHIT353
(Plasmid #204506)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 204506 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pHIT283 (derived from L4417)
  • Vector type
    Other

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CeRep55 tandem repeats from Y73B3A (C. elegans)
  • Species
    C. elegans (nematode)
  • Promoter double-T7

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SphI (unknown if destroyed)
  • 3′ cloning site NotI (unknown if destroyed)
  • 5′ sequencing primer L4440 [Caldwell lab; Addgene]
  • 3′ sequencing primer f1 origin, reverse primer (CTAGGGCGCTGGCAAGTGT)
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The number of tandem repeats in the insert could be slightly smaller than the number in the digital sequence file, but it does not affect hybridization experiments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pHIT353 was a gift from Yuji Kohara (Addgene plasmid # 204506 ; http://n2t.net/addgene:204506 ; RRID:Addgene_204506)
  • For your References section:

    A small RNA system ensures accurate homologous pairing and unpaired silencing of meiotic chromosomes. Tabara H, Mitani S, Mochizuki M, Kohara Y, Nagata K. EMBO J. 2023 Jun 1;42(11):e105002. doi: 10.15252/embj.2020105002. Epub 2023 Apr 20. 10.15252/embj.2020105002 PubMed 37078421
