pUN1213 - pL0_p16OMT (pro + 5U)
(Plasmid #203890)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 203890 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pICH41295
  • Backbone manufacturer
    Weber et al., 2011 (DOI:10.1371/journal.pone.0016765)
  • Vector type
    Plant Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    16OMT promoter and 5'UTR
  • Species
    Catharanthus roseus var. LBE
  • Insert Size (bp)
    1047
  • Mutation
    Mutation of BpiI and/or BsaI cut sites for MoClo domestication: G>C -607 bp from start codon; C>G -37 bp from start codon

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (destroyed during cloning)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pUN1213 - pL0_p16OMT (pro + 5U) was a gift from Carolyn Lee-Parsons (Addgene plasmid # 203890 ; http://n2t.net/addgene:203890 ; RRID:Addgene_203890)

  • For your References section:

    The role of the Golden2-like (GLK) transcription factor in regulating terpenoid indole alkaloid biosynthesis in Catharanthus roseus. Cole-Osborn LF, McCallan SA, Prifti O, Abu R, Sjoelund V, Lee-Parsons CWT. Plant Cell Rep. 2024 May 14;43(6):141. doi: 10.1007/s00299-024-03208-9. 10.1007/s00299-024-03208-9 PubMed 38743349
