PB-NLS-ZapCV2
(Plasmid #203664)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 203664 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    piggyback
  • Backbone manufacturer
    Liu Laboratory at CU Boulder
  • Vector type
    Mammalian Expression
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    ZapCV2 Zinc sensor
  • Alt name
    NLS-ZapCV2
  • Species
    Synthetic
  • GenBank ID
  • Promoter CMV promoter
  • Tag / Fusion Protein
    • SV40 NLS (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer T7 Forward
  • 3′ sequencing primer BGH Reverse
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PB-NLS-ZapCV2 was a gift from Amy Palmer (Addgene plasmid # 203664 ; http://n2t.net/addgene:203664 ; RRID:Addgene_203664)

  • For your References section:

    Human cells experience a Zn(2+) pulse in early G1. Rakshit A, Holtzen SE, Lo MN, Conway KA, Palmer AE. Cell Rep. 2023 Jun 16;42(6):112656. doi: 10.1016/j.celrep.2023.112656. 10.1016/j.celrep.2023.112656 PubMed 37330912
