Addgene

pCAGGS-Twin-Strep-TEV-DGKζ
(Plasmid #202531)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 202531 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCAGGS-N-TEV-Twin-Strep
  • Backbone manufacturer
    Chiaki Murakami
  • Backbone size w/o insert (bp) 4884
  • Total vector size (bp) 7671
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    DGKZ
  • Alt name
    Diacylglycerol kinase zeta 1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2787
  • GenBank ID
    U51477.1 NM_001199267.2
  • Entrez Gene
    DGKZ (a.k.a. DAGK5, DAGK6, DGK-ZETA, hDGKzeta)
  • Promoter CAG
  • Tags / Fusion Proteins
    • Twin-Strep-tag (N terminal on backbone)
    • TEV cleavable site (N terminal on backbone)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer TTCGGCTTCTGGCGTGTGACC
  • 3′ sequencing primer TATTAGCCAGAAGTCAGATGCTCAAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCAGGS-Twin-Strep-TEV-DGKζ was a gift from Chiaki Murakami (Addgene plasmid # 202531 ; http://n2t.net/addgene:202531 ; RRID:Addgene_202531)

  • For your References section:

    Diacylglycerol kinase zeta interacts with sphingomyelin synthase 1 and sphingomyelin synthase-related protein via different regions. Furuta M, Murakami C, Numagami Y, Suzuki R, Sakane F. FEBS Open Bio. 2023 May 11. doi: 10.1002/2211-5463.13628. 10.1002/2211-5463.13628 PubMed 37166445
