pL0_EF-BCA
(Plasmid
#202158)
-
PurposeLevel 0 plasmid containing a terminator sequence from gene 51305 from Phaeodactylum tricornutum with EF overhangs used to build a level 1 construct.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 202158 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 * |
* Log in to view industry pricing.
Backbone
-
Vector backbonepL0R
-
Vector typeSynthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameBCA terminator
-
SpeciesPhaeodactylum tricornutum
-
Insert Size (bp)258
-
MutationNone
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pL0_EF-BCA was a gift from Christopher Dupont (Addgene plasmid # 202158 ; http://n2t.net/addgene:202158 ; RRID:Addgene_202158) -
For your References section:
Universal loop assembly: open, efficient and cross-kingdom DNA fabrication. Pollak B, Matute T, Nunez I, Cerda A, Lopez C, Vargas V, Kan A, Bielinski V, von Dassow P, Dupont CL, Federici F. Synth Biol (Oxf). 2020;5(1):ysaa001. doi: 10.1093/synbio/ysaa001. Epub 2020 Feb 5. 10.1093/synbio/ysaa001 PubMed 32161816
