pAAV-DIO-CAG-hM4Di-P2A-dTomato
(Plasmid #202037)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 202037 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAAV
  • Backbone size w/o insert (bp) 5062
  • Total vector size (bp) 7324
  • Vector type
    AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    hM4Di
  • Species
    Synthetic
  • Insert Size (bp)
    2232
  • Promoter CAG
  • Tag / Fusion Protein
    • dTomato (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site AscI (not destroyed)
  • 5′ sequencing primer cctacagctcctgggcaacgtgc
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-DIO-CAG-hM4Di-P2A-dTomato was a gift from Yoav Ben-Simon & Peter Jonas (Addgene plasmid # 202037 ; http://n2t.net/addgene:202037 ; RRID:Addgene_202037)
