pmEGFP-tHe-Tub5
(Plasmid #201738)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 201738 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3973
  • Total vector size (bp) 6102
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    tHe-Tub5
  • Species
    Hypsibius exemplaris
  • Insert Size (bp)
    1389
  • GenBank ID
    OQ282848
  • Promoter CMV
  • Tag / Fusion Protein
    • mEGFP (N terminal on backbone)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CMV Forward (CGCAAATGGGCGGTAGGCGTG)
  • 3′ sequencing primer SV-40 pA Reverse (GAAATTTGTGATGCTATTGC)
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pmEGFP-tHe-Tub5 was a gift from Stanislav Vinopal (Addgene plasmid # 201738 ; http://n2t.net/addgene:201738 ; RRID:Addgene_201738)

  • For your References section:

    Phylogenetic and functional characterization of water bears (Tardigrada) tubulins. Novotna Floriancicova K, Baltzis A, Smejkal J, Czernekova M, Kaczmarek L, Maly J, Notredame C, Vinopal S. Sci Rep. 2023 Mar 30;13(1):5194. doi: 10.1038/s41598-023-31992-z. 10.1038/s41598-023-31992-z PubMed 36997657
