pMAH-pnRFP
(Plasmid #201679)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 201679 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMAH
  • Backbone size w/o insert (bp) 7000
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    pnRFP
  • Species
    Synthetic
  • Insert Size (bp)
    803

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Hind III (not destroyed)
  • 3′ cloning site ApaI (not destroyed)
  • 5′ sequencing primer CGC AAA TGG GCG GTA GGC GTG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMAH-pnRFP was a gift from Huiwang Ai (Addgene plasmid # 201679 ; http://n2t.net/addgene:201679 ; RRID:Addgene_201679)

  • For your References section:

    Development, Characterization, and Structural Analysis of a Genetically Encoded Red Fluorescent Peroxynitrite Biosensor. Pang Y, Huang M, Fan Y, Yeh HW, Xiong Y, Ng HL, Ai HW. ACS Chem Biol. 2023 Jun 16;18(6):1388-1397. doi: 10.1021/acschembio.3c00139. Epub 2023 May 15. 10.1021/acschembio.3c00139 PubMed 37185019
