GG-EBNA-MIR302-3g-EEA-2g-PGK-Puro
(Plasmid
#201677)
-
PurposeEBNA episome plasmid for U6 promoter-driven expression of 3 gRNAs targeting miRNA302/367 (Addgene #201960) and 2 gRNAs targeting EEA-motif (Addgene #102898). Includes PGK-puro selection cassette
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 201677 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneGG-EBNA
-
Vector typeMammalian Expression, CRISPR
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameMIR302-3g-EEA-2g-PGK-Puro
-
gRNA/shRNA sequence3 MIR302/367 and 2 EEA gRNAs, see full sequence
-
SpeciesH. sapiens (human)
- Promoter U6
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site XbaI (unknown if destroyed)
- 3′ cloning site NotI (unknown if destroyed)
- 5′ sequencing primer T7 (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
GG-EBNA-MIR302-3g-EEA-2g-PGK-Puro was a gift from Timo Otonkoski (Addgene plasmid # 201677 ; http://n2t.net/addgene:201677 ; RRID:Addgene_201677) -
For your References section:
CRISPR activation enables high-fidelity reprogramming into human pluripotent stem cells. Sokka J, Yoshihara M, Kvist J, Laiho L, Warren A, Stadelmann C, Jouhilahti EM, Kilpinen H, Balboa D, Katayama S, Kyttala A, Kere J, Otonkoski T, Weltner J, Trokovic R. Stem Cell Reports. 2022 Feb 8;17(2):413-426. doi: 10.1016/j.stemcr.2021.12.017. Epub 2022 Jan 20. 10.1016/j.stemcr.2021.12.017 PubMed 35063129
