CF-iSH
(Plasmid #20159)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 20159 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    ECFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4733
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CFP-FKBP-p85
  • Alt name
    p85
  • Species
    M. musculus (mouse)
  • Entrez Gene
    Pik3r2 (a.k.a. p85beta)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Xho1 (not destroyed)
  • 3′ cloning site EcoR1 (not destroyed)
  • 5′ sequencing primer n/a
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CF-iSH was a gift from Tobias Meyer (Addgene plasmid # 20159 ; http://n2t.net/addgene:20159 ; RRID:Addgene_20159)

  • For your References section:

    Rapid chemically induced changes of PtdIns(4,5)P2 gate KCNQ ion channels. Suh BC, Inoue T, Meyer T, Hille B. Science. 2006 Dec 1. 314(5804):1454-7. 10.1126/science.1131163 PubMed 16990515
