pCMV6-AN-DDK_WT RAD23A
(Plasmid #201438)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 201438 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCMV6-AN-DDK
  • Backbone manufacturer
    Origene
  • Backbone size w/o insert (bp) 5929
  • Total vector size (bp) 7022
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    UV excision repair protein RAD23 homolog A
  • Alt name
    hHR23A
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1092
  • Entrez Gene
    RAD23A (a.k.a. HHR23A, HR23A)
  • Promoter CMV
  • Tag / Fusion Protein
    • FLAG (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AsiSI (not destroyed)
  • 3′ cloning site HindIII (unknown if destroyed)
  • 5′ sequencing primer TAATACGACTCACTATAGG
  • 3′ sequencing primer CAGGAAACAGCTATGAC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMV6-AN-DDK_WT RAD23A was a gift from Roger Woodgate (Addgene plasmid # 201438 ; http://n2t.net/addgene:201438 ; RRID:Addgene_201438)

  • For your References section:

    A novel interaction between RAD23A/B and Y-family DNA polymerases. Ashton NW, Jaiswal N, Cestari Moreno N, Semenova IV, D'Orlando DA, Teatin Latancia M, McIntyre J, Woodgate R, Bezsonova I. J Mol Biol. 2023 Nov 5:168353. doi: 10.1016/j.jmb.2023.168353. 10.1016/j.jmb.2023.168353 PubMed 37935254
