PGK EGFP-LC3B
(Plasmid #200427)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 200427 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pEGFPc1/PGK
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 5100
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    MAP1LC3B
  • Alt name
    microtubule associated protein 1 light chain 3 beta
  • Alt name
    LC3B
  • Alt name
    ATG8F
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    405
  • GenBank ID
    NM_022818.5
  • Entrez Gene
    MAP1LC3B (a.k.a. ATG8F, LC3B, MAP1A/1BLC3, MAP1LC3B-a)
  • Promoter PGK
  • Tag / Fusion Protein
    • EGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer 5'-TAGTGTGGGCCCTGTTCCTG
  • 3′ sequencing primer 5'-CTTTATTTGTAACCATTATAAGCTGC
    • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Modified from PGK mCherry-LC3B

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PGK EGFP-LC3B was a gift from Erika Holzbaur (Addgene plasmid # 200427 ; http://n2t.net/addgene:200427 ; RRID:Addgene_200427)

  • For your References section:

    Regulatory imbalance between LRRK2 kinase, PPM1H phosphatase, and ARF6 GTPase disrupts the axonal transport of autophagosomes. Dou D, Smith EM, Evans CS, Boecker CA, Holzbaur ELF. Cell Rep. 2023 May 1;42(5):112448. doi: 10.1016/j.celrep.2023.112448. 10.1016/j.celrep.2023.112448 PubMed 37133994
