pIA027
(Plasmid
#200418)
-
Purpose(Empty Backbone) amyE::(dronPA cm), for dronPA fusions. PALM-compatible integration vector for Bacillus subtilis. Includes dronPA photoswitchable FP with multi cloning sites (MCS) for fast and interchangeable cloning.
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 200418 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepDG364
- Backbone size (bp) 6310
-
Vector typeBacterial Expression
-
Selectable markersChloramphenicol
-
Tag
/ Fusion Protein
- dronPA (C terminal on backbone)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Growth instructionsE. coli: 37°C and selection Ampicillin 100 μg/mL B. subtilis: 30°C and selection Chloramphenicol 5 μg/mL
-
Copy numberLow Copy
Cloning Information
- Cloning method Gibson Cloning
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
The dronPA sequence was amplified from pEYY99 using primers oIA010 and oIA047, then cloned into pIA021 digested with BamHI and SbfI, resulting in plasmid pIA027
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pIA027 was a gift from Rut Carballido-López (Addgene plasmid # 200418 ; http://n2t.net/addgene:200418 ; RRID:Addgene_200418) -
For your References section:
New PALM-compatible integration vectors for use in the Gram-positive model bacterium Bacillus subtilis. Altinoglu I, Carballido-Lopez R. bioRxiv 2023 10.1101/2023.03.16.532899
