Modular BE4max for GG insertion
(Plasmid #198891)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 198891 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    BE4max
  • Backbone size w/o insert (bp) 4197
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CRISPR associated protein 9
  • Alt name
    SpCas9
  • Alt name
    Cas9
  • Species
    Streptococcus pyogenes
  • Insert Size (bp)
    4101
  • Entrez Gene
    cas9 (a.k.a. DQM35_RS05165, NCTC12064_01025, csn1)
  • Promoter CMV
  • Tags / Fusion Proteins
    • NLS (N terminal on insert)
    • NLS (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note there is a E>K mutation in Cas9n. Depositor confirms mutation does not affect plasmid function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Modular BE4max for GG insertion was a gift from Reuben Harris (Addgene plasmid # 198891 ; http://n2t.net/addgene:198891 ; RRID:Addgene_198891)

  • For your References section:

    APOBEC Reporter Systems for Evaluating diNucleotide Editing Levels. Rieffer AE, Chen Y, Salamango DJ, Moraes SN, Harris RS. CRISPR J. 2023 Oct;6(5):430-446. doi: 10.1089/crispr.2023.0027. Epub 2023 Sep 6. 10.1089/crispr.2023.0027 PubMed 37672599
