pBad-HaloGFP-163-166
(Plasmid #198622)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 198622 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    PBad
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 4000
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    HaloGFP-163-166
  • Species
    Synthetic
  • Insert Size (bp)
    1614
  • Promoter araBAD promoter

Cloning Information

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBad-HaloGFP-163-166 was a gift from Robert Campbell (Addgene plasmid # 198622 ; http://n2t.net/addgene:198622 ; RRID:Addgene_198622)
  • For your References section:

    Chemigenetic indicators based on synthetic chelators and green fluorescent protein. Zhu W, Takeuchi S, Imai S, Terada T, Ueda T, Nasu Y, Terai T, Campbell RE. Nat Chem Biol. 2023 Jan;19(1):38-44. doi: 10.1038/s41589-022-01134-z. Epub 2022 Sep 22. 10.1038/s41589-022-01134-z PubMed 36138142
