Addgene

pDV06 [punc-17::SNG-1::CRY2(535)]
(Plasmid #197597)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 197597 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    RM#348p
  • Backbone manufacturer
    J. Rand
  • Vector type
    Worm Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Synaptogyrin-CRY2 (E490G + residues 1-535)
  • Alt name
    SNG-1::CRY2olig(535)
  • Alt name
    SNG-1
  • Alt name
    CRY2
  • Species
    C. elegans (nematode), A. thaliana (mustard weed)
  • Insert Size (bp)
    3483
  • Mutation
    E490G
  • Entrez Gene
    CRY2 (a.k.a. AT1G04400, AT-PHH1, ATCRY2, CRYPTOCHROME 2 APOPROTEIN, F19P19.14, F19P19_14, FHA, PHH1, cryptochrome 2)
  • Entrez Gene
    sng-1 (a.k.a. CELE_T08A9.3)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDV06 [punc-17::SNG-1::CRY2(535)] was a gift from Alexander Gottschalk (Addgene plasmid # 197597 ; http://n2t.net/addgene:197597 ; RRID:Addgene_197597)

  • For your References section:

    Rapid and reversible optogenetic silencing of synaptic transmission by clustering of synaptic vesicles. Vettkotter D, Schneider M, Goulden BD, Dill H, Liewald J, Zeiler S, Guldan J, Ates YA, Watanabe S, Gottschalk A. Nat Commun. 2022 Dec 19;13(1):7827. doi: 10.1038/s41467-022-35324-z. 10.1038/s41467-022-35324-z PubMed 36535932
