pUC19-π-EB1_EF1α-mCherry
(Plasmid #197429)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 197429 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pUC19
  • Backbone size w/o insert (bp) 2682
  • Total vector size (bp) 9016
  • Vector type
    CRISPR, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    EF1α-based π-element with HDR templates flanking MAPRE1 exon 5 insertion site
  • Alt name
    EB1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    6334
  • GenBank ID
    NM_012325.2
  • Entrez Gene
    MAPRE1 (a.k.a. EB1)
  • Tags / Fusion Proteins
    • GCN4 leucine zipper
    • LOV2
    • mCherry
    • Zdk1

Cloning Information

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pUC19-π-EB1_EF1α-mCherry was a gift from Torsten Wittmann (Addgene plasmid # 197429 ; http://n2t.net/addgene:197429 ; RRID:Addgene_197429)

  • For your References section:

    Growth cone advance requires EB1 as revealed by genomic replacement with a light-sensitive variant. Dema A, Charafeddine R, Rahgozar S, van Haren J, Wittmann T. Elife. 2023 Jan 30;12:e84143. doi: 10.7554/eLife.84143. 10.7554/eLife.84143 PubMed 36715499
