pAAVS1_EF1a-MitoTrap-mCherry-IRES-Puro
(Plasmid
#197067)
-
PurposeDonor plasmid for human AAVS1 locus knock-in, constitutive expression of MitoTrap-mCherry
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 197067 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSH-EFIRES-P
-
Vector typeMammalian Expression, CRISPR
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameMitoTrap-mCherry
-
GenBank ID
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byAddgene plasmid #129715 was used in the creation of this plasmid. Mitotrap was derived from Addgene plasmid #46942.
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://www.biorxiv.org/content/10.1101/2022.12.10.519870v1 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAAVS1_EF1a-MitoTrap-mCherry-IRES-Puro was a gift from Julia Mahamid (Addgene plasmid # 197067 ; http://n2t.net/addgene:197067 ; RRID:Addgene_197067) -
For your References section:
Genetically encoded multimeric tags for subcellular protein localization in cryo-EM. Fung HKH, Hayashi Y, Salo VT, Babenko A, Zagoriy I, Brunner A, Ellenberg J, Muller CW, Cuylen-Haering S, Mahamid J. Nat Methods. 2023 Dec;20(12):1900-1908. doi: 10.1038/s41592-023-02053-0. Epub 2023 Nov 6. 10.1038/s41592-023-02053-0 PubMed 37932397
