pRB051_LEU2
(Plasmid
#196993)
-
Purpose(Empty Backbone) Big-IN Payload yeast assembly vector. Encodes LEU2 yeast selectable marker and components for bacterial copy number induction. Contains a mammalian transient (backbone) GFP-T2A-BSD selection cassette.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 196993 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonecostum
-
Backbone manufacturerThe Center for Synthetic Regulatory Genetics at NYU Langone Health
- Backbone size (bp) 13328
-
Vector typeMammalian Expression, Mouse Targeting, Cre/Lox, Synthetic Biology ; Yeast assembly vector for Big-IN payloads
-
Selectable markersBlasticidin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)TransforMax EPI300
-
Growth instructionsCopy number induction is recommended for high yield preps. See Lucigen’s growth and copy number induction protocol for TransforMax EPI300 cells.
-
Copy numberLow Copy
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please visit https://www.biorxiv.org/content/10.1101/2022.06.20.495832v3 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pRB051_LEU2 was a gift from Matthew Maurano (Addgene plasmid # 196993 ; http://n2t.net/addgene:196993 ; RRID:Addgene_196993) -
For your References section:
Synthetic regulatory genomics uncovers enhancer context dependence at the Sox2 locus. Brosh R, Coelho C, Ribeiro-Dos-Santos AM, Ellis G, Hogan MS, Ashe HJ, Somogyi N, Ordonez R, Luther RD, Huang E, Boeke JD, Maurano MT. Mol Cell. 2023 Apr 6;83(7):1140-1152.e7. doi: 10.1016/j.molcel.2023.02.027. Epub 2023 Mar 16. 10.1016/j.molcel.2023.02.027 PubMed 36931273
