pES002 MBP-GSK3β_S9A-HA-His
(Plasmid #196184)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 196184 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pMBP-MG
  • Backbone manufacturer
    New England Biolabs
  • Backbone size w/o insert (bp) 6716
  • Total vector size (bp) 9466
  • Modifications to backbone
    Modified to include an N-terminal TEV-cleavable MBP tag and a C-terminal His6 tag
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    GSK3B
  • Alt name
    Glycogen Synthase Kinase 3β
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1305
  • Mutation
    changed Serine 9 to Alanine
  • GenBank ID
    2932 BC000251
  • Entrez Gene
    GSK3B
  • Promoter Tac
  • Tags / Fusion Proteins
    • MBP (N terminal on backbone)
    • His6 (C terminal on backbone)
    • HA (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer MalE Forward GGTCGTCAGACTGTCGATGAAGCC
  • 3′ sequencing primer M13F Reverse TGTAAAACGACGGCCAGT
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Addgene #14753

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pES002 MBP-GSK3β_S9A-HA-His was a gift from Jesse Zalatan (Addgene plasmid # 196184 ; http://n2t.net/addgene:196184 ; RRID:Addgene_196184)
  • For your References section:

    The Axin scaffold protects the kinase GSK3beta from cross-pathway inhibition. Gavagan M, Jameson N, Zalatan JG. Elife. 2023 Aug 7;12:e85444. doi: 10.7554/eLife.85444. 10.7554/eLife.85444 PubMed 37548359
