pAAV_hSynapsin1_NOPLight1
(Plasmid
#195580)
-
PurposeExpresses NOPLight1 in neurons
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 195580 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Want a viral vector made from this plasmid?
Make a packaging request and we'll get back to you.
Please log in to submit a packaging request.
-
SerotypeSelect serotype for details See details about
-
PricingSelect serotype and quantity $ USD for preparation of µL virus + $30 USD for plasmid.
-
How this works
- Place a request for a quantity of 10 (1 mL), 25 (2.5 mL), or 50 (5 mL). Our all-inclusive pricing includes DNA production and QC.
- Addgene will quickly confirm that we can produce a high-quality prep for you.
- Track your request and place an order from within your account. Payment information must be added before we can begin processing your order.
- Receive your prep in 6–9 weeks after the MTA is approved by your organization.
- Learn more about our Packaged on Request Service.
Backbone
-
Vector backbonepAAV-hSynapsin1
-
Backbone manufacturerUZH Viral Vector Facility
- Backbone size w/o insert (bp) 4464
- Total vector size (bp) 6387
-
Vector typeMammalian Expression, AAV
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature30°C
-
Growth Strain(s)NEB Stable
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameNOPLight1
-
SpeciesH. sapiens (human), Synthetic
-
Insert Size (bp)1923
- Promoter human Synapsin-1
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site HindIII (not destroyed)
- 5′ sequencing primer gtcgagattaattaactcgagcaggtaag
- 3′ sequencing primer cgccacgttgcctgacaacgggccacaac (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
See https://www.biorxiv.org/content/10.1101/2023.05.26.542102v2 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAAV_hSynapsin1_NOPLight1 was a gift from Tommaso Patriarchi (Addgene plasmid # 195580 ; http://n2t.net/addgene:195580 ; RRID:Addgene_195580) -
For your References section:
Development of a genetically encoded sensor for probing endogenous nociceptin opioid peptide release. Zhou X, Stine C, Prada PO, Fusca D, Assoumou K, Dernic J, Bhat MA, Achanta AS, Johnson JC, Pasqualini AL, Jadhav S, Bauder CA, Steuernagel L, Ravotto L, Benke D, Weber B, Suko A, Palmiter RD, Stoeber M, Kloppenburg P, Bruning JC, Bruchas MR, Patriarchi T. Nat Commun. 2024 Jun 25;15(1):5353. doi: 10.1038/s41467-024-49712-0. 10.1038/s41467-024-49712-0 PubMed 38918403
