pCS2-Arl13b-mCardinal
(Plasmid #194542)

• Purpose: Expresses Arl13b with mCardinal in mammalian cells and zebrafish embryos
• Depositing Lab: Heidi Hehnly
• Publication: Aljiboury et al PLoS Genet. 2023 May 15;19(5):e1010765. doi: 10.1371/journal.pgen.1010765. eCollection 2023 May.

Backbone

• Vector backbone: pCS2
• Backbone size w/o insert (bp): 4067
• Total vector size (bp): 6082
• Vector type: Mammalian Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: Unknown

Gene/Insert

• Gene/Insert name: Arl13b
• Species: M. musculus (mouse)
• Insert Size (bp): 1290
• Entrez Gene: Arl13b (a.k.a. A530097K21Rik, A930014M17Rik, Arl2l1, C530009C10Rik, hnn)
• Promoter: CMV IE94
• Tag / Fusion Protein:
  • mCardinal (C terminal on insert)

Cloning Information

• Cloning method: Gibson Cloning
• 5′ sequencing primer: sp6
• 3′ sequencing primer: T3

Resource Information

• A portion of this plasmid was derived from a plasmid made by: Arl13b was received from the Pazour lab at UMass Med.

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
