pTK73.ChrV_oxTi365.gRNA
(Plasmid #194052)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 194052 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pTK73
  • Vector type
    Worm Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ChrV_oxTi365 sgRNA
  • Alt name
    CGGTCGCGGTACTCCAAAT
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    18
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsaI (destroyed during cloning)
  • 3′ cloning site BsaI (destroyed during cloning)
  • 5′ sequencing primer M13 Forward
  • 3′ sequencing primer M13 Reverse
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

An identical plasmid has been reported by Dr. Shinsuke Niwa's group.
doi.org/10.1371/journal.pone.0197128

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTK73.ChrV_oxTi365.gRNA was a gift from Kota Mizumoto (Addgene plasmid # 194052 ; http://n2t.net/addgene:194052 ; RRID:Addgene_194052)

  • For your References section:

    Targeting endogenous proteins for spatial and temporal knockdown using auxin-inducible degron in Caenorhabditis elegans. Kurashina M, Mizumoto K. STAR Protoc. 2023 Jan 13;4(1):102028. doi: 10.1016/j.xpro.2022.102028. 10.1016/j.xpro.2022.102028 PubMed 36640369
