vHB16
(Plasmid #193455)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 193455 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    vHB08
  • Backbone size w/o insert (bp) 10758
  • Total vector size (bp) 10777
  • Vector type
    CRISPR
  • Selectable markers
    geneticin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    tRNA-gRNA
  • gRNA/shRNA sequence
    rbp1
  • Species
    Acanthamoeba castellanii
  • Promoter U6

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer CTGGGCGGTGACTAAtctag
  • 3′ sequencing primer gttgttccgggtcgactctaG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    vHB16 was a gift from Chantal Abergel (Addgene plasmid # 193455 ; http://n2t.net/addgene:193455 ; RRID:Addgene_193455)

  • For your References section:

    Evolution of giant pandoravirus revealed by CRISPR/Cas9. Bisio H, Legendre M, Giry C, Philippe N, Alempic JM, Jeudy S, Abergel C. Nat Commun. 2023 Jan 26;14(1):428. doi: 10.1038/s41467-023-36145-4. 10.1038/s41467-023-36145-4 PubMed 36702819
