GB1839
(Plasmid #193103)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 193103 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDG3_Alpha1
  • Vector type
    Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GB_SynP gRNA2
  • gRNA/shRNA sequence
    GCTGTATCTAATAGAATCTT
  • Species
    Synthetic

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GB1839 was a gift from Diego Orzaez (Addgene plasmid # 193103 ; http://n2t.net/addgene:193103 ; RRID:Addgene_193103)

  • For your References section:

    GB_SynP: A Modular dCas9-Regulated Synthetic Promoter Collection for Fine-Tuned Recombinant Gene Expression in Plants. Moreno-Gimenez E, Selma S, Calvache C, Orzaez D. ACS Synth Biol. 2022 Sep 16;11(9):3037-3048. doi: 10.1021/acssynbio.2c00238. Epub 2022 Aug 31. 10.1021/acssynbio.2c00238 PubMed 36044643
