Addgene

EB3-mNeonGreen
(Plasmid #191761)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 191761 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    peGFP-N1
  • Backbone size w/o insert (bp) 3886
  • Total vector size (bp) 5548
  • Vector type
    Mammalian Expression, Bacterial Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    EB3-mNeonGreen
  • Alt name
    MAPRE3
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1563
  • Entrez Gene
    MAPRE3 (a.k.a. EB3, EBF3, EBF3-S, RP3)
  • Promoter CMV
  • Tag / Fusion Protein
    • mNeonGreen (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (unknown if destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer TACGGTGGGAGGTCTAT
  • 3′ sequencing primer TCTACAAATGTGGTATGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    EB3-mNeonGreen was a gift from Daniel Gerlich (Addgene plasmid # 191761 ; http://n2t.net/addgene:191761 ; RRID:Addgene_191761)

  • For your References section:

    A mitotic chromatin phase transition prevents perforation by microtubules. Schneider MWG, Gibson BA, Otsuka S, Spicer MFD, Petrovic M, Blaukopf C, Langer CCH, Batty P, Nagaraju T, Doolittle LK, Rosen MK, Gerlich DW. Nature. 2022 Sep;609(7925):183-190. doi: 10.1038/s41586-022-05027-y. Epub 2022 Aug 3. 10.1038/s41586-022-05027-y PubMed 35922507
