pAAV2-CAGIG-H2B-V5-mScarlet
(Plasmid #191093)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 191093 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pAAV2-CAGIG
  • Backbone manufacturer
    Original was from the Boyden laboratory
  • Backbone size w/o insert (bp) 4718
  • Total vector size (bp) 5861
  • Modifications to backbone
    The originalpAAV2-CAG backbone has been shortened and added more restriction enzymes to make it more modular and delete specific parts for substitutions with other pieces of DNA.
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    H2B and mScarlet
  • Species
    Synthetic
  • Insert Size (bp)
    1143
  • Mutation
    The fusion protein was optimized to the Human codon usage
  • GenBank ID
    NP_001100822
  • Promoter CMV and CAG
  • Tag / Fusion Protein
    • H2B-V5-mScarlet (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRV (not destroyed)
  • 5′ sequencing primer pCAGG-5
  • 3′ sequencing primer WPRE-R
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV2-CAGIG-H2B-V5-mScarlet was a gift from Murray Blackmore & Pantelis Tsoulfas (Addgene plasmid # 191093 ; http://n2t.net/addgene:191093 ; RRID:Addgene_191093)
  • For your References section:

    Brain-wide analysis of the supraspinal connectome reveals anatomical correlates to functional recovery after spinal injury. Wang Z, Romanski A, Mehra V, Wang Y, Brannigan M, Campbell BC, Petsko GA, Tsoulfas P, Blackmore MG. Elife. 2022 Jul 15;11. pii: 76254. doi: 10.7554/eLife.76254. 10.7554/eLife.76254 PubMed 35838234
