SF-U7snRNA-CypA-E4
(Plasmid #190695)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 190695 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pRRL
  • Backbone size w/o insert (bp) 6114
  • Total vector size (bp) 6545
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    U7 snRNA antisense CypA Exon 4
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    431
  • Promoter U7 promoter

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site PstI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer na
  • 3′ sequencing primer na
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please note that the Addgene verified sequence differs from the depositor's reference sequence. These minor differences should not affect plasmid function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    SF-U7snRNA-CypA-E4 was a gift from Pim Pijnappel (Addgene plasmid # 190695 ; http://n2t.net/addgene:190695 ; RRID:Addgene_190695)

  • For your References section:

    Antisense Oligonucleotides Promote Exon Inclusion and Correct the Common c.-32-13T>G GAA Splicing Variant in Pompe Disease. van der Wal E, Bergsma AJ, Pijnenburg JM, van der Ploeg AT, Pijnappel WWMP. Mol Ther Nucleic Acids. 2017 Jun 16;7:90-100. doi: 10.1016/j.omtn.2017.03.001. Epub 2017 Mar 14. 10.1016/j.omtn.2017.03.001 PubMed 28624228
