pL6-H2B-iRFP720-bla
(Plasmid #189991)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 189991 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLenti6-bla
  • Backbone size w/o insert (bp) 6794
  • Total vector size (bp) 8138
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Human histone H2B
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1868
  • Tag / Fusion Protein
    • iRFP720 (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site MluI (not destroyed)
  • 3′ cloning site ClaI (not destroyed)
  • 5′ sequencing primer --
  • 3′ sequencing primer --
    • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    H2B-iRFP720 was subcloned from Addgene Plasmid #128961

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pL6-H2B-iRFP720-bla was a gift from Achim Kramer (Addgene plasmid # 189991 ; http://n2t.net/addgene:189991 ; RRID:Addgene_189991)

  • For your References section:

    Circadian period is compensated for repressor protein turnover rates in single cells. Gabriel CH, Del Olmo M, Rizki Widini A, Roshanbin R, Woyde J, Hamza E, Gutu NN, Zehtabian A, Ewers H, Granada A, Herzel H, Kramer A. Proc Natl Acad Sci U S A. 2024 Aug 20;121(34):e2404738121. doi: 10.1073/pnas.2404738121. Epub 2024 Aug 14. 10.1073/pnas.2404738121 PubMed 39141353
