HRV-B3 IRES
(Plasmid #189969)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 189969 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pRC
  • Backbone size w/o insert (bp) 1882
  • Total vector size (bp) 2516
  • Vector type
    Cloning

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    HRV-B3 IRES
  • Insert Size (bp)
    634
  • Promoter N/A

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsmBI (from pRC0940) (destroyed during cloning)
  • 3′ cloning site BsmBI (from pRC0940) (destroyed during cloning)
  • 5′ sequencing primer ggccttttgctggccttttgc
  • 3′ sequencing primer GATAATCGCGGCCGCGGTC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    HRV-B3 IRES was a gift from Howard Chang (Addgene plasmid # 189969 ; http://n2t.net/addgene:189969 ; RRID:Addgene_189969)

  • For your References section:

    Engineering circular RNA for enhanced protein production. Chen R, Wang SK, Belk JA, Amaya L, Li Z, Cardenas A, Abe BT, Chen CK, Wender PA, Chang HY. Nat Biotechnol. 2022 Jul 18. pii: 10.1038/s41587-022-01393-0. doi: 10.1038/s41587-022-01393-0. 10.1038/s41587-022-01393-0 PubMed 35851375
