pTP-PCR C1
(Plasmid #189618)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 189618 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pPtGE31
  • Backbone manufacturer
    Slattery et al. 2018
  • Backbone size w/o insert (bp) 11728
  • Total vector size (bp) 57631
  • Modifications to backbone
    Inserted the T. pseudonana mitochondrial genome into the backbone of pPtGE31 and URA3
  • Vector type
    Bacterial Expression, Yeast Expression, Synthetic Biology ; Diatom Expression
  • Selectable markers
    URA3, HIS3 ; Nourseothricin

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    EPI300 (Epicentre)
  • Growth instructions
    Optional: Arabinose induction to high plasmid copy number.
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Mitochondrial Genome of Thalassiosira pseudonana
  • Alt name
    T. pseudonana
  • Alt name
    Mitochondrial Genome
  • Species
    T. pseudonana
  • Insert Size (bp)
    43830
  • Mutation
    Minor additional mutations described in manuscript
  • GenBank ID
    NC_007405.1

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTP-PCR C1 was a gift from Bogumil Karas (Addgene plasmid # 189618 ; http://n2t.net/addgene:189618 ; RRID:Addgene_189618)

  • For your References section:

    Cloning of Thalassiosira pseudonana's Mitochondrial Genome in Saccharomyces cerevisiae and Escherichia coli. Cochrane RR, Brumwell SL, Shrestha A, Giguere DJ, Hamadache S, Gloor GB, Edgell DR, Karas BJ. Biology (Basel). 2020 Oct 26;9(11). pii: biology9110358. doi: 10.3390/biology9110358. 10.3390/biology9110358 PubMed 33114477
