pAAV-CAG-miniGFP2-P2A-FusionRed
(Plasmid #188734)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 188734 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pAAV
  • Backbone size w/o insert (bp) 4717
  • Total vector size (bp) 5845
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    miniGFP2
  • Species
    Synthetic
  • Insert Size (bp)
    330
  • Promoter CAG
  • Tag / Fusion Protein
    • FusionRed

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer GCAACGTGCTGGTTATTGTG
  • 3′ sequencing primer CATAGCGTAAAAGGAGCAACA
    • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-CAG-miniGFP2-P2A-FusionRed was a gift from Kiryl Piatkevich (Addgene plasmid # 188734 ; http://n2t.net/addgene:188734 ; RRID:Addgene_188734)

  • For your References section:

    Enhanced small green fluorescent proteins as a multisensing platform for biosensor development. Liang GT, Lai C, Yue Z, Zhang H, Li D, Chen Z, Lu X, Tao L, Subach FV, Piatkevich KD. Front Bioeng Biotechnol. 2022 Oct 17;10:1039317. doi: 10.3389/fbioe.2022.1039317. eCollection 2022. 10.3389/fbioe.2022.1039317 PubMed 36324888
