flag-RapR-PTP1B
(Plasmid #188656)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 188656 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA
  • Backbone size w/o insert (bp) 5359
  • Total vector size (bp) 6951
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    PTP1B
  • Alt name
    PTPN1
  • Insert Size (bp)
    1592
  • Promoter CMV
  • Tag / Fusion Protein
    • flag (N terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    flag-RapR-PTP1B was a gift from Andrei Karginov (Addgene plasmid # 188656 ; http://n2t.net/addgene:188656 ; RRID:Addgene_188656)

  • For your References section:

    Dissecting protein tyrosine phosphatase signaling by engineered chemogenetic control of its activity. Fauser J, Huyot V, Matsche J, Szynal BN, Alexeev Y, Kota P, Karginov AV. J Cell Biol. 2022 Aug 1;221(8). pii: 213352. doi: 10.1083/jcb.202111066. Epub 2022 Jul 13. 10.1083/jcb.202111066 PubMed 35829702
